Model
25 PATRIOT
25 Patriot: Designed for 6-Man Catfishing Teams and Guiding Services
The 25 Patriot is the perfect choice for a 6-man catfishing team or professional guiding services, offering unmatched space, comfort, and performance. With its innovative design, the fuel tank has been relocated under the mid-center section of the cockpit, optimizing weight distribution and enhancing stability, whether you're fishing or guiding. The 6-seating arrangement option is the first of its kind in its class, ensuring all crew members have ample space for a comfortable and efficient day on the water.
boat specs
Overall Length:
25′8′′
Beam:
102′′
Degree of Deadrise:
12°
Max HP:
430
Weight:
3,500 lbs.
Approx. Fuel Capacity:
56 Gal.
Standard options:
- 24’2” LOA 102” beam width (including motor pod)
- Heavy duty 12 degree dead rise delta pad bottom
- 0.190” aluminum bottom
- 0.190” bows and 0.190” bow doubler plate
- 4 HD bottom lifting strakes
- One part formed gunnel
- 0.125” sides
- Notched and ventilated full reverse chine bottom
- 9 longitudinal stringers with chines integrated
- Full height rear sloping transom for big water and back trolling
- Full height motor splash well
- 14” wide x 93” long x 12” deep gunnel top rod boxes with LED lighting & locking latches
- Self bailing watertight front deck, with large center lid and twin gas shock assist
- 5 window split walk thru style dashes with 2 step storage box
- Center mounted DOT 2 tinted laminated safety glass (rubber molding style)
- Single color paint on gunnels and windshield frames – (standard color white) – (other colors may cost more)
- Standard side vinyl wrap – customer color choice only
- SEA STAR 1.4 CU. IN. hydraulic helm with steering cylinder and all hoses
- Large glove box with locking door
- Chrome tread plate cockpit floor and deck skins
- Reinforced bow trolling motor mount
- 90 gallon rear elevated live well with single lid, white LED lighting, and gas shock assist
- (6) switch main accessory panel with power point
- (6) switch ACC. panel for pumps and aerators with power point
- (2) 800 GPH live well fill pumps, (1) 800 GPH recirculation pump
- (3) timers - two for fill pumps, one for recirculate pump
- (2) 1000 GPH automatic bilge pumps
- Heavy duty welded sonar dash mount
- 69 gallon aluminum front fuel tank
- (2) rod box lids with locking latches
- (1) bow cap rope storage bin with locking latch
- (1) front deck lid with locking latch - (all keyed the same)
- (2) dash mounted cup holders
- Navigational & anchor lighting
- (2) front Millennium M-100 seats (grey) with locking rotator and slide
- (2) rear Millennium M-100 seats (grey) removable with 2-3/8” flush mount pedestals
- (10) LED interior lights – (3) white storage, (1) live well, (4) red cockpit, and (2) red rod lights
- (2) LED 3” cube landing lights
- Wash down pump with coil hose, gun, and filter
- Single wiper with low/high and auto-park – driver's side only
- Start battery only
Available options:
- High back seat with fixed arm rest upgrade (ea.)
- Smooth Move shock migration seating with rotator (ea.)
- Custom front entry ladder, trailer mounted
- Passenger side wiper
- Rear step / storage compartment full width – 73”x12” C/W white LED
- Rear step / storage compartment half width – 32”x12” C/W white LED
- Galvanized trailer
